Description
| Specifications | |||||||||||||||||||
| DEVICE PRESENTATION | MODULE | MOUNTING BOX SIZE | 25MM | ||||||||||||||||
| SWITCH FUNCTION | 1-WAY | VERTICAL STRUCTURE | |||||||||||||||||
| NUMBER OF ROCKER | 2 | ENDURANCE | 40000 | ||||||||||||||||
| RATED CURRENT | 10A | ENCLOSURE MATERIAL | PC PANEL，OUTER FRAME,PRESSURE PLATE,IRON BRACKET(Q195)，BASE(PP) | ||||||||||||||||
| RATED VOLTAGE | 250V AC | CONTACT MATERIAL | BRASS,SILVER POINT | ||||||||||||||||
| FREQUENCY | 50/60 Hz | TERMINAL MATERIAL | IRON PLATED WITH BULE-WHITE ZINC | ||||||||||||||||
| PRODUCT DIMENSIONS | 86MM*86MM | TERMINAL IDENTIFIER | COM，L | ||||||||||||||||
| ACCESSORIES PRODUCT | MOUNTING SCREWS 25 X M3.5 |
CONDUCTOR SIZE | 1~2.5MM² | ||||||||||||||||
| MOUNTING ARRANGEMENT | FLUSH MOUNTING | TERMINAL CAPACITY | COM:16X1MM²,9X1.5MM²,5X2.5MM² L:9X1MM²,6X1.5MM²,4X2.5MM² |
||||||||||||||||
| FIXING CENTER | 60.3MM | TIGHTENING TORAUE | 0.6N.M | ||||||||||||||||
| AUXILARY FIXING OPTIONS | 2 CORNERS | SCREW SIZE | M3.5*6.5 M4*8 | ||||||||||||||||
