Description
| Specifications | |||||||||||||||||||
| DEVICE PRESENTATION | MODULE | MOUNTING BOX SIZE | 25MM | ||||||||||||||||
| SWITCH FUNCTION | – | ACTUATING MEMBER | – | ||||||||||||||||
| NUMBER OF ROCKER | – | ENDURANCE | 30000 | ||||||||||||||||
| RATED CURRENT | 13A | ENCLOSURE MATERIAL | PC PANEL，OUTER FRAME,PRESSURE PLATE,IRON BRACKET(Q195)，BASE(PP) | ||||||||||||||||
| RATED VOLTAGE | 250V AC | CONTACT MATERIAL | BRASS,SILVER POINT | ||||||||||||||||
| FREQUENCY | 50/60 HZ | TERMINAL MATERIAL | IRON PLATED WITH BULE-WHITE ZINC | ||||||||||||||||
| PRODUCT DIMENSIONS | 86MM*86MM | TERMINAL IDENTIFIER | L, N & E | ||||||||||||||||
| ACCESSORIES PRODUCT | MOUNTING SCREWS 25 X M3.5 |
CONDUCTOR SIZE | 1.5~4MM² | ||||||||||||||||
| MOUNTING ARRANGEMENT | FLUSH MOUNTING | TERMINAL CAPACITY | 6X1.5MM² 5X2MM² 3X4MM²” |
||||||||||||||||
| FIXING CENTER | 60.3MM | TIGHTENING TORAUE | 0.6N.M | ||||||||||||||||
| AUXILARY FIXING OPTIONS | 2 CORNERS | SCREW SIZE | M4*7.5 | ||||||||||||||||
